The Stillroom Vault file format

Everything Stillroom keeps is in one folder. On a Mac that’s ~/Library/Application Support/Stillroom/Store. This page describes every file in it, exactly enough to read a vault without the app. tools/stillroom-open.py does that in about 300 lines of Python, and tools/test-stillroom-open.sh checks it against a vault the app writes.

This is format 4, the format of Stillroom 1.0; nothing older is read.

Nothing here is secret. A vault opens with its password, its recovery key, or enough pieces of its emergency kit, and with nothing else. Publishing the format gives no one a way in.

The pieces

All sealing is AES-256-GCM in Apple CryptoKit’s combined form:

nonce (12 bytes) | ciphertext | tag (16 bytes)

Changing any byte makes it fail to open. Big-endian is used for every number.

Most seals also carry authenticated data: a few bytes naming what was sealed, which aren’t stored but must be given again to open it. A sealed file copied into another’s place then fails to open. Each is listed where it’s used below.

Two slots

The folder holds two slots, a/ and b/, built exactly alike. When a vault is made, yours goes in one of them at random, and nothing records which. The other is a real slot sealed with a random password, recovery key and kit secret nobody knows. Setting a decoy password replaces it with a new, empty slot whose password you chose. Every way in is tried on both slots.

Store/
  a/  b/          password.key, recovery.key, kit.key, cover.key, list, search
  intruder.pub    both slots' intruder public keys
  intruder/       the intruder log
  touchid.key     when Touch ID is on (it opens one slot)
  mac.key         when Lock to this Mac is on
  Files/          both slots' items

The slot key

Each slot’s slot key is 32 random bytes made with the slot. It’s never written down unsealed. Each way in is the slot key, sealed by a key made from something you know:

touchid.key, at the top, seals one slot’s key with a key in this Mac’s Secure Enclave, released by your fingerprint. It isn’t readable off this Mac. Try the key it gives on both slots’ cover.key.

A key file is laid out like this:

"VA2" 0x01 | memory KiB (u32) | passes (u32) | lanes (u32) | salt (16) | sealed slot key

The sealing key is Argon2id (version 0x13, RFC 9106). It’s made from the UTF-8 password with that salt, memory, passes and lanes, and is 32 bytes long. New vaults use 524288 KiB (512 MB), 3 passes and 4 lanes. Readers refuse costs outside 1–16 lanes, 1–10 passes and 8 × lanes KiB to 2 GiB, as a damaged or doctored file. A key file without the VA2 mark is damaged.

The cover key

The cover key is 32 random bytes, made once with the vault and the same in both slots. Each slot’s cover.key is the cover key sealed with that slot’s key, authenticated data Vault cover key 4 followed by the slot’s letter (a or b).

Each slot’s list and search sit inside a cover, sealed with the cover key:

sealed with the cover key, authenticated data "Vault cover 4" | "list" or "search" | letter:
    length of what's inside (u64) | the slot's sealed list or index | zero bytes

Stillroom writes both slots’ covers of a kind together, the same size and with the same date, so a copy of the folder can’t tell which slot changed. To read a slot: open cover.key with the slot key, the cover with the cover key, and the list inside with the slot key.

Lock to this Mac

With Lock to this Mac on, mac.key holds a Secure Enclave P-256 key. Both slots’ password.key are then sealed a second time, outside the layout above, with an AES key derived from it by ECDH and HKDF-SHA256. That outer seal only opens on this Mac. recovery.key and kit.key are never locked this way, so they open their slot anywhere.

The list of files

Inside each slot’s list cover: UTF-8 JSON sealed with the slot key, with authenticated data Vault list 3 (UTF-8), padded at the end with spaces. A list holding any files is wrapped as {"format": 4, "vault": { … }}. A list with no files is written bare, as below, so every empty list is the same size. Readers should refuse a format they don’t know.

{ "files": [ { "id": "UUID", "name": "w2.pdf", "uti": "com.adobe.pdf", "size": 52011,
               "addedAt": 783000000.0, "folder": "Taxes/2025", "modifiedAt": null,
               "created": 561000000.0, "contentModified": 561000000.0,
               "tags": ["tax"], "entry": null, "chunked": null, "sealedAs": "UUID", "key": "base64 (32 bytes)",
               "versions": [ { "id": "UUID", "date": 782000000.0, "size": 50002, "chunked": null,
                               "sealedAs": "UUID", "key": "base64 (32 bytes)" } ] } ],
  "folders": ["Taxes", "Taxes/2025"],
  "showInCapture": false, "intruder": "base64 (32 bytes)", "touchID": "base64 (64 bytes, zeros when none)",
  "kitMade": "000000000000", "kitReminded": "000000000000" }

• Dates are seconds since 1 January 2001, UTC (Apple’s reference date).
• size is the real size in bytes.
• entry is "note" for a note (Markdown text) or "secret" for a secret (JSON: {"template": …, "fields": [{"id", "label", "value", "concealed"}]}). It’s null for a file.
• key is this sealing’s own item key, 32 random bytes made fresh every time the item (or that version) is sealed. Every item and version has one; a list naming one without is damaged.
• sealedAs is a fresh 16-byte id made with each sealing: 8 random bytes, then the first 8 bytes of HMAC-SHA256 over them, keyed with HKDF-SHA256 of the cover key (no salt, info Vault names 4 and the slot’s letter, 32 bytes). It’s always set, and it names the blob. The tag lets a slot tell its own files from the other’s in the shared Files/.
• intruder is the slot’s intruder private key (see below). touchID is the public key in the touchid.key this slot made. kitMade and kitReminded are whole seconds since 2001, 12 digits, zeros for none. All are always written, at fixed lengths.

Each file’s contents

Each sealing (an item’s current contents, or one earlier version), of either slot, is a file of its own in Files/:

Files/<sealedAs>.stillroom, sealed with the item key. The name never changes: making a version current only changes the list.

Every item is padded to its Padmé length before sealing, so sealed sizes give away at most about 12%:

padded(n) = n                                  if n <= 1
            e = floor(log2 n); s = floor(log2 e) + 1
            mask = 2^(e - s) - 1; (n + mask) & ~mask   otherwise

A file is in one of two forms:

• One piece: the padded bytes, sealed once with the item key and authenticated data Vault item 3 (UTF-8) | sealedAs (16 raw UUID bytes). Keep the first size bytes.

• Chunks, when chunked is true (big files, all audio and video). The blob starts with "VLT2":

  "VLT2" | chunk size (u32, 1 MiB) | chunk 0 | chunk 1 | … | last chunk

  • There are max(1, ceil(padded(size) / chunk size)) chunks. Each holds a full chunk of plaintext except the last, which holds the rest of the padded length.
  • Each chunk is sealed with the item key and authenticated data sealedAs (16 raw UUID bytes) | chunk index (u64) | 1 if last else 0.
  • Keep the first size bytes across the chunks.

The emergency kit

The kit’s secret is 16 random bytes, split by Shamir’s secret sharing over GF(256). It’s the AES field, reduced by x⁸ + x⁴ + x³ + x + 1, with one random polynomial per byte and the secret as its constant term. Any threshold pieces rebuild it by Lagrange interpolation at x = 0.

A piece is 21 bytes:

version (1) | threshold | index (1-255) | share (16) | first 2 bytes of SHA-256 over the 19 bytes before

It’s written in Crockford base32 (0-9 A-Z without I L O U) as VK- followed by groups of four. Readers should accept any case, spaces or dashes anywhere, O for 0, and I or L for 1.

Other files

Stillroom doesn’t need either to read files.
